Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction equipment. Machines such as boom lifts, aerial lifts and manlifts. These kinds of machines are designed to facilitate access to hard to reach areas, buildings and roofs, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and includes handholds or platforms or steps that are connected to the unit to be able to move personnel from every floor.
TB85
The Terex TB85 offers a maximum working height of 91 feet. Moreover, the maximum height of the platform reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of 70 feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is approximately 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height reaches 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
